Technical specifications
Can be installed on a frame with a 68mm Euro-type square-taper bottom bracket (with English threading).Bottom bracket width: 68mmLength: 113 mm.Also available in 110mm, 115mm, 118mm and 122.5mmBearing material: SteelType: SquareBottom bracket type: BSC/BSA (English, Euro)Weight: 302 g
Assembly tips
Bottom bracket tightening torque: 50-70N.mCrank tightening torque: 35-50N.mRemember to grease the bottom bracket thread to facilitate screwing and unscrewing.
Maintenance tips
Do not use a high-pressure cleaner on bearings
Need any help?
The technicians at your Decathlon store are at your service to help you replace your bike parts. Feel free to ask them for help!
Shimano reliability!
Praline Flavour
Designed for bottom brackets with a square taper.
Rolling efficiency
Sealed cartridge bearing
Maintain
Repair your product and give it a new lease of life.
